What is SM490B Steel?Dimensional Characteristics of JIS G3106 SM490B steel

SM490B steel is a material grade and designation defined in JIS G3106 standard. SM490B offers low yield and tensile strength and is supplied with a variety of treatments. JIS G3106 SM490B is mainly used for welded structure steel plates, sheets, strips for Architecture, Engineering Structures.

The Chemical Composition of SM490B Steels:

JIS G3106 defines the percentage of chemical composition of SM490B steels as under:
Maximum Carbon (C) percentage is 0.18.
Maximum Manganese (Mn) percentage is 1.65.
Maximum percentage of Phosphorous (P) is 0.035.
Maximum percentage of Sulphur (S) is 0.035.
Maximum percentage of Silicon (Si) is 0.55.
Remaining is iron (Fe) percentage and with few negligible impurities.

Mechanical Property of SM490B Steel

Grade	SM490BMechanical Property
Grade	Thickness	Yield	Tensile	Elongation
SM490B	mm	Min Mpa	Mpa	Min%
	t≦16	325	490-610	17
	16<t≦90	295-315	490-610	23

Equivalent grades of grade SM490B (1.8818)

Equivalent steel grade of SM490B
Europe	Belgium	Germany	France	Italy	Sweden	India	USA	U.K
S 355 JR	AE 355 B	-	E 36-2	Fe 510 B	SS21,32,01	IS 961	A633gr A,C,D	50 B

JIS G3106 SM490B steel Key Points

Standard: JIS G3106
Steel grade:SM400A, SM400B, SM400C, SM490A, SM490B, SM490C, SM490YA, SM490YB, SM520B, SM520C, SM570
Dimension range: 1.5mm -620mm x 1000mm-4000mm x 1000mm-18000mm
We can supply any size based on customer's requirements.
MOQ: 1 PC
Delivery time: Promptly (Stock) or 10-40 days (Production)

Shanghai Katalor Enterprises Co., Ltd is a big complex combined steel stockist whose business related with trade, processing, storage and transportation. we are specialized in supplying SM490B steel. We have the good quality and advanced equipment, our products meet the state standard, and also available for customers' requirement. If you have any need of JIS G3106 SM490B steel, please do not hesitate to contact us by email [email protected], we can do our best to help you!
